C-Band 800-100W
The RevGo 800W and 1000W (1kW) C-Band Block Up-Converters (BUCs) represent the pinnacle of high-power satellite earth station RF technology. Designed for heavy-duty uplink architectures, these high-power amplifiers operate seamlessly within the standard and extended C-band frequencies, converting incoming L-band signals into massive high-frequency transmissions capable of driving demanding global networks. [1]
BUC/SSPA KEY FEATURES
- Wide channel separation capable for multi-carriers and multi-transponders
- Variable power consumption 4000 W @60 dBm
- Independently removable fans (Patent Pending)
- High Stability Internal 10 MHz Reference with Auto-DetectionOPTIONAL
- Equipment redundancy configurations (1:1/1:2 redundancy system)OPTIONAL
- ugged design for extreme environments
TECHNICAL SPECIFICATIONS
| Parameter | Standard / 800 W | Extended / 1000 W |
|---|---|---|
| RF Frequency | 5.850 - 6.425 GHz | 5.850 - 6.725 GHz |
| IF Frequency | 950 - 1525 MHz | 950 - 1825 MHz |
| LO Frequency | 4.90 GHz | 4.90 GHz |
| External Ref | 10 MHz, 0±5 dBm (internal ref optional) | 10 MHz, 0±5 dBm (internal ref optional) |
| Saturated Power | 59.5 dBm | 60.5 dBm |
| Rated Power | 59 dBm | 60 dBm |
| Plin1 | 58 dBm | 59 dBm |
| Plin2 | 57 dBm | 58 dBm |
| Plin3 | 56 dBm | 57 dBm |
| IMD3 (@Prated-3dB) | -25 dBc | -25 dBc |
| Small Signal Gain | 75 dB | 75 dB |
| Gain Stability | 3 dB p-p | 3 dB p-p |
| Gain Adjustment | 20 dB (55-75 dB, Step: 0.1 dB) | 20 dB (55-75 dB, Step: 0.1 dB) |
| Pout Detection Range | Prated to (Prated - 20 dB) | Prated to (Prated - 20 dB) |
| Parameter / Feature | Value / Specification |
|---|---|
| Gain Variation | 1.5 dB p-p / 40 MHz 3 dB p-p / 575 MHz 4 dB p-p / 875 MHz |
| TX Noise Density | -76 dBm/Hz |
| RX Noise Density | -150 dBm/Hz @ 3.4 - 4.2 GHz |
| Phase Noise | -68 dBc / Hz @ 100 Hz -80 dBc / Hz @ 1 KHz -85 dBc / Hz @ 10 KHz -95 dBc / Hz @ 100 KHz |
| Output Spurious | -60 dBc min. / -65 dBc typ. @ In-band spurs |
