Ultra-Mobile X/Y Pedestal for Multi-Orbit Satellites
The PXY-240-MIL is an ultra-mobile, small-footprint X/Y pedestal solution engineered for rapid high-speed connectivity across LEO, MEO, GEO, and HEO regimes. Fully compliant with MIL-STD-810 and MIL-STD-461, this agile system packs into compact transit cases for effortless tactical deployment, achieving a complete tool-free setup in less than 30 minutes.
Mission Agility Target Acquisition
Built for absolute field flexibility, the terminal supports standby, manual, pointing, programme, auto, and memory tracking modes. It achieves autonomous target acquisition by locking onto modem SNR, beacon, or carrier signals without external equipment. Real-time spectrum monitoring is available via an intuitive web interface or an ACU-connected tablet, while dual GPS receivers ensure a swift multi-orbit lock.
Precision Tracking & Modular Architecture
Driven by a high-performance servo mechanism, the terminal delivers seamless, zero-keyhole tracking during high-speed satellite passes. Its modular design allows a single operator to quickly swap sub-components and switch frequency bands in the field. For optimal tactical efficiency, a single power source feeds all critical internal modules, while tool-less quick-release captive bolts ensure effortless hardware replacements and firmware updates.
- X, Ku and Ka-Band versions are available
- Precision Carbon Fiber Reflector
- Quickly Replaceable Feed and RF Chain
- Integrated Monitoring System on web GUI
- Modular Design
- TLE tracking
- Auto Pointing on Beacon/DVB/Modem/SNR
- Overhead full tracking capability
- Easy to deploy
- Embedded Spectrum Analyzer Display OPTIONAL
| GENERAL SPECIFICATIONS | PXY-240 | ||||
| Reflector Diameter | 2.4m Carbon-Fiber | ||||
| Reflector Type | Segmented b | ||||
| Tracking Method | Sun, TLE, Program Tracking | ||||
| Power Supply | 1 Phase 120-240 VAC 50/60 Hz | ||||
| DC Power Input | 24 to 48VDC | ||||
| RF CHARACTERISTIC | X-Band | Ku-Band | Ka-Band | ||
| Frequency (GHz) Tx | 7.90 - 8.40 GHz | 13.75 - 14.50 GHz | 27.5 - 31.0 | ||
| Frequency (GHz) Rx | 7.25 - 7.75 GHz | 10.70 - 12.75 GHz | 17.7 - 21.2 | ||
| Antenna Gain (±0.2 dBi) Tx | ≥ 43.8 | ≥ 48.5 | ≥ 54.2 | ||
| Antenna Gain (±0.2 dBi) Rx | ≥ 43.1 | ≥ 47.0 | ≥ 50.7 | ||
| VSWR | ≤1.3:1 | ≤1.3:1 | ≤ 1.3:1 | ||
| RF Interface | WR-112 | WR-75 | Tx WR-2, Rx WR-42 | ||
| Polarization | Circular | Linear | Circular | ||
| Axial Ratio (dB) | ≤1.5 | ≥35 dB (CPI) | ≤ 1.5 (Rx) / ≤1.0 (Tx) | ||
| Antenna Pattern Compliance | Compliant with ITU-R S.465-6, ITU-R S.580-6 | ||||
| MECHANICAL SPECIFICATIONS | X Axis | Y Axis | Polarization for KU | ||
| Antenna Motion Range | ± 90° | ± 90° | ± 90° | ||
| Antenna Drive Rate | 0.1° - 6° /s | 0.1° - 6° /s | 0.1° - 6° /s | ||
| Antenna Acceleration | 5²/sec² | 5²/sec² | 5²/sec² | ||
| Motor | DC Brushless Servo with Brakes | DC Brushless Servo with Brakes | DC Brushless Servo with Brakes | ||
| ENVIRONMENTAL SPECIFICATIONS | |||||
| Temperature Range Operational | -30°C - +55°C | ||||
| Temperature Range Survival | -40°C - +70°C | ||||
| Wind Speed Operational | Gusting 72 km/h | ||||
| Wind Speed Survival | Gusting 120 km/h | ||||
| Protection Grade | IP65 | ||||
| Solar Radiation | 1135W/m2 | ||||
| Relative Humidity | %100 Condensed | ||||
