PFA-370

  • Brands:
  • Product Code:
  • Stock:
  • PALS
  • PFA-370
  • In Stock

Overview

PFA-370 is designed as a portable 3.7m antenna system. It can operate on C, X, Ku, Ka bands and in different configurations. The reflector structure consists of lightweight carbon-fiber panels. Feed options can be RxO, Tx/Rx, 2-ports or multiple ports. Polarization can be circular or linear according to feed options. Customized design and different feed arm options are possible to provide interchangeable feed structure. The reflector is assembled with 19 carbon-fiber panels. It is designed to be lightweight and modular with robust components.
It supports manual, auto and one button capture satellite within 5 minutes. Its feed structure assures high gain, low side lobe and perfect RF performance.
PFA-370’s motorized version can be used with PALS PAC550 military type antenna controller. It is provided with GPS system, position detection system, polarization adjustment system, servo drive system and high performance satellite beacon receiving system.


Download Catalogue

GENERAL SPECIFICATIONS

  • Reflector Diameter
  • 3.7m
  • Reflector Type
  • Circular, axially symmetric with 19 carbon-fiber panels, prime focus feed
  • Operation On-Air Time
  • 5 Minutes after Set-Up
  • Antenna Concept
  • Portable design with pedestal, trailer, tactical, tripod, mobile mounts.

Key Features

• C, X, Ku, Ka Band options are available

• Multiple mount options (mobile, pedestal, tactical, tripod, trailer mounts)

• 19 reflector panels (carbon-fiber)

• Motorized or non-motorized versions

• 9 transport cases (standard)

• Installation within 30 minutes

• Designed to comply with Mil-Spec standards

• Optional beacon tracking

• Optional de-ice system

• Manual drive tool kit for emergency situations

• High gain, low side-lobe, high accuracy and very good cross polar rejection (> 35 dB)

Compatibility

  • • MIL-STD-810G Compliant
  • • MIL-STD-1472 Compliant
  • • MIL-STD-188-164A Compliant
  • • ITU-RS-580 Compliant
  • • ITU-RS-465-6 Compliant
  • •EUTELSAT

RF CHARACTERISTIC

  • Frequency (GHz) Tx
  • 13.75 - 14.50 GHz
  • Frequency (GHz) Rx
  • 10.70 - 12.75 GHz
  • Antenna Gain (±0.2 dBi) Tx
  • 52.6 dBi @ Midband
  • Antenna Gain (±0.2 dBi) Rx
  • 51 dBi @Midband
  • Polarization
  • Linear
  • Feed lnsertion Loss Tx
  • 0.8 dB
  • Feed lnsertion Loss Rx
  • 0.3 dB
  • Waveguide lnterface
  • WR -75
  • VSWR
  • 1.3:1
  • Cross-Polar lsolation
  • 35 dB
  • G/T
  • 28.5 dB/K
  • C Band Frequency Tx
  • 5.850-6.425 GHz
  • C Band Frequency Rx
  • 3.625-4.200 GHz
  • C Band Gain Tx
  • 45.1 @6.00GHz
  • C Band Gain Rx
  • 41.6 @4.00GHz
  • X Band Frequency Tx
  • 7.90-8.40 GHz
  • X Band Frequency Rx
  • 7.25-7.75 GHz
  • X Band Gain Tx
  • 47.7 @8.15GHz
  • X Band Gain Rx
  • 47.0 @7.50GHz
  • Ka Band Frequency Tx
  • 27.50-31.00 GHz
  • Ka Band Frequency Rx
  • 17.70-21.20 GHz
  • Ka Band Gain Tx
  • 58.3 @30.00GHz
  • Ka Band Gain Rx
  • 54.8 @20.00GHz
  • Azimuth Drive Rates
  • 0.3° /s
  • Elevation Drive Rates
  • 0.5° /s
  • Polarization Drive Rates
  • 0.5° /s
  • Azimuth Antenna Travels
  • ± 180° *
  • Elevation Antenna Travels
  • 0° to 90°
  • Polarization Antenna Travels
  • ± 90°
  • Manual Override Mechanism
  • Manual override for elevation and azimuth drive system
  • Mount Type
  • Elevation over Azimuth
  • Operational Limits
  • Hardware and software settable

Key Features

• C, X, Ku, Ka Band options are available

• Multiple mount options (mobile, pedestal, tactical, tripod, trailer mounts)

• 19 reflector panels (carbon-fiber)

• Motorized or non-motorized versions

• 9 transport cases (standard)

• Installation within 30 minutes

• Designed to comply with Mil-Spec standards

• Optional beacon tracking

• Optional de-ice system

• Manual drive tool kit for emergency situations

• High gain, low side-lobe, high accuracy and very good cross polar rejection (> 35 dB)

Compatibility

  • • MIL-STD-810G Compliant
  • • MIL-STD-1472 Compliant
  • • MIL-STD-188-164A Compliant
  • • ITU-RS-580 Compliant
  • • ITU-RS-465-6 Compliant
  • •EUTELSAT

ENVIRONMENTAL SPECIFICATIONS

  • Temperature Operational
  • -30°C to +60°C
  • Temperature Survival
  • - 40°C to +70°C
  • Wind Speed Operational
  • 60 km/h (optional 72 km/h with pedestal mount)
  • Wind Speed Survival
  • 120 km/h (optional 150 km/h with pedestal mount)
  • Humidity (Relative)
  • 0-100%
  • Altitude
  • 4000 m
